| Bearing No. | Boundary Dimensions | Basic Load Ratings | Limiting Speed | Weight | |||||||||
| 51400 | 53400 | 53400U | d | D | B | r min | Cr | Cor | Grease | Oil | 51400 | 53400 | 53400U |
| mm | mm | mm | mm | KN | KN | rpm | rpm | kg | kg | kg | |||
| 51405 | 53405 | 53405U | 25 | 60 | 24 | 1 | 55.6 | 89.4 | 2600 | 4000 | 0.34 | 0.35 | 0.442 |
| 51406 | 53406 | 53406U | 30 | 70 | 28 | 1 | 72.8 | 126 | 2200 | 3400 | 0.53 | 0.53 | 0.66 |
| 51407 | 53407 | 53407U | 35 | 80 | 32 | 1.1 | 87.1 | 155 | 1900 | 2900 | 0.79 | 0.79 | 0.96 |
| 51408 | 53408 | 53408U | 40 | 90 | 36 | 1.1 | 113 | 205 | 1700 | 2600 | 1.14 | 1.12 | 1.37 |
| 51409 | 53409 | 53409U | 45 | 100 | 39 | 1.1 | 130 | 242 | 1500 | 2300 | 1.47 | 1.5 | 1.82 |
| 51410 | 53410 | 53410U | 50 | 110 | 43 | 1.5 | 148 | 283 | 1400 | 2100 | 1.99 | 1.97 | 2.38 |
| 51411 | 53411 | 53411U | 55 | 120 | 48 | 1.5 | 178 | 359 | 1200 | 1900 | 2.64 | 2.57 | 3.1 |
| 51412 | 53412 | 53412U | 60 | 130 | 51 | 1.5 | 201 | 397 | 1100 | 1700 | 3.51 | 3.44 | 4.13 |
| 51413 | 53413 | 53413U | 65 | 140 | 56 | 2 | 232 | 493 | 1000 | 1600 | 4.47 | 4.47 | 5.28 |
| 51414 | 53414 | 53414U | 70 | 150 | 60 | 2 | 250 | 553 | 940 | 1450 | 5.48 | 5.38 | 6.37 |
| 51415 | 53415 | 53415U | 75 | 160 | 65 | 2 | 252 | 560 | 880 | 1350 | 6.75 | 6.64 | 7.87 |
| 51416 | 53416 | 53416U | 80 | 170 | 68 | 2.1 | 270 | 621 | 810 | 1250 | 7.97 | 7.84 | 9.22 |
| 51417 | 53417 | 53417U | 85 | 180 | 72 | 2.1 | 307 | 753 | 780 | 1200 | 9.29 | 9.2 | 10.8 |
