Plastic Pillow Block - SSUCPPA

PRODUCTS

LOCATION: HOME - PRODUCTS - Plastic Pillow Block

SSUCPPA

TYPE	d	a	b	h	m	c	s	g	n	Bi	W
TYPE	(mm)	a	b	h	m	c	s	g	n	Bi	kg
TB204	20	33.3	34.5	66	50.8	72.8	3/8-16	13	12.7	31	0.085
TB205	25	36.5	39.5	73.5	50.8	76.2	3/8-16	13	14.3	34.1	0.115
TB206	30	42.9	42.5	84	76.2	101	7/16-14	16	15.9	38.1	0.17
TB207	35	47.6	47.5	95	82.6	110	1/2-13	18	17.5	42.9	0.25
TB208	40	49.2	48	100.5	88.9	120	1/2-13	20	19	49.2	0.29
TB209	45	54	50	108.5	95.3	124	1/2-13	20	19	49.2	0.34
TB210	50	57.2	54	115	101.6	135	5/8-11	22	19	51.6	0.43

TYPE	d	a	e	h	b	s	c	Bi	n	g	W
TYPE	(mm)	a	e	h	b	s	c	Bi	n	g	kg
PA204	20	76	52	33.3	38	M8	64	31	12.7	13	0.09
PA205	25	84	56	36.5	38	M10	72	34.1	14.3	13	0.12
PA206	30	94	66	42.9	48	M10	84	38.1	15.9	16	0.18
PA207	35	110	80	47.6	48	M10	95	49.2	17.5	18	0.26
PA208	40	116	84	49.2	54	M12	100	49.2	19	20	0.3
PA209	45	120	90	54.2	54	M12	108	49.2	19	20	0.35
PA210	50	130	94	57.2	60	M16	116	51.6	19	22	0.45
