| 轴承座型号 | 基本尺寸 | 重量 | 适用轴承型号 | ||||||||||
| Dimensions | |||||||||||||
| Housing No. | Da | I | a | e | j | g | Be | s | f | p | k | Weight | Bearing No |
| (kg) | |||||||||||||
| FC201 | 47 | 10 | 100 | 55.1 | 5 | 20.5 | 17 | 12 | 62 | 78 | 7 | 0.55 | UC201 |
| FC202 | 47 | 10 | 100 | 55.1 | 5 | 20.5 | 17 | 12 | 62 | 78 | 7 | 0.55 | UC202 |
| FC203 | 47 | 10 | 100 | 55.1 | 5 | 20.5 | 17 | 12 | 62 | 78 | 7 | 0.55 | UC203 |
| FC204 | 47 | 10 | 100 | 55.1 | 5 | 20.5 | 17 | 12 | 62 | 78 | 7 | 0.55 | UC204 |
| FC205 | 52 | 10 | 115 | 63.6 | 6 | 21 | 17 | 12 | 70 | 90 | 7 | 0.8 | UC205 |
| FC206 | 62 | 10 | 125 | 70.7 | 8 | 23 | 19 | 12 | 80 | 100 | 8 | 1 | UC206 |
| FC207 | 72 | 11 | 135 | 77.8 | 8 | 26 | 20 | 14 | 90 | 110 | 9 | 1.2 | UC207 |
| FC208 | 80 | 11 | 145 | 84.8 | 10 | 26 | 21 | 14 | 100 | 120 | 9 | 1.45 | UC208 |
| FC209 | 85 | 10 | 160 | 93.3 | 12 | 26 | 22 | 16 | 105 | 132 | 14 | 2.1 | UC209 |
| FC210 | 90 | 10 | 165 | 97.6 | 12 | 28 | 23 | 16 | 110 | 138 | 14 | 2.1 | UC210 |
| FC211 | 100 | 13 | 185 | 106.1 | 12 | 31 | 24 | 19 | 125 | 150 | 15 | 3.1 | UC211 |
| FC212 | 110 | 17 | 195 | 113.1 | 12 | 36 | 26 | 19 | 135 | 160 | 15 | 3.2 | UC212 |
